SRC-370SH-4730 Factory Hot Selling 4.5V 17500rmp 3.63A Output 11.51W
Product Description
Product Description
| PMDC MOTOR Technical Data | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Model | Rated Voltage (V) | No-Load | Rated | Stall | |||||||
| Operating Range | Nominal | Speed (RPM) | Current (mA) | Speed (RPM) | Current (mA) | Torque (mN.m / gf.cm) | Power (W) | Current (mA) | Torque (mN.m / gf.cm) | ||
| RF-370CA | 061700 | 6.0~24.0 | 24 VDC | 1320 | 3 | 1000 | 8 | 0.98/10 | 0.1 | 260 | 4.02/41 |
| 20123 | 3.0~6.0 | 6 VDC | 8000 | 70 | 6878 | 420 | 2.4/24.5 | 1.71 | 2550 | 17/173 | |
| RC-370SH | 4730 | 3.0~5.0 | 4.5 VDC | 17500 | 550 | 15199 | 3630 | 7.2/73.4 | 11.51 | 24000 | 55/561 |
| 18139 | 6.0~12.0 | 12 VDC | 10000 | 130 | 8439 | 700 | 5.8/59.2 | 5.17 | 3800 | 37.5/382.5 | |
💡
Review the technical parameters above for precise motor performance specifications.
Application
Frequently Asked Questions (FAQ)
❓ What is the rated voltage of the RC-370SH-4730 PMDC motor?
The RC-370SH-4730 model operates at a nominal rated voltage of 4.5 VDC, with an operating range of 3.0V to 5.0V.
❓ What are the no-load speed and current specs for the RC-370SH-4730?
Under no-load conditions, the motor reaches a speed of 17,500 RPM with a current draw of 550 mA.
❓ What is the power output of this motor?
The RC-370SH-4730 model delivers a rated output power of 11.51 W with a rated speed of 15,199 RPM.
❓ What are the typical applications for these PMDC motors?
These versatile PMDC motors are commonly used in security systems, smart home devices, automotive parts, toys, and small consumer electronics due to their compact size and high efficiency.
❓ What stall torque does the RC-370SH-4730 provide?
It features a stall torque of 55 mN.m (561 gf.cm) and a stall current of 24,000 mA.
❓ Are there other voltage models available in the 370 series?
Yes, other configurations in the series include nominal voltage designs of 6 VDC, 12 VDC, and 24 VDC to suit different application requirements.
