Valex Motor
12 Dc Motor 9000 Rpm Brush Micro Motor 6-24v Is Available
Product Description
| PMDC MOTOR Technical Data | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Model | Rated Voltage (V) | No-Load | Rated | Stall | |||||||
| Operating Range | Nominal | Speed (RPM) | Current (A) | Speed (RPM) | Current (A) | Torque (mN.m / gf.cm) | Power (W) | Current (A) | Torque (mN.m / gf.cm) | ||
| RS-380SH | 4052 | 3.0~6.0 | 4.8VDC | 7800 | 0.32 | 6701 | 1.95 | 9.9/101 | 6.98 | 11.9 | 70.6/720 |
| 3557 | 6.0~12.0 | 12VDC | 21200 | 0.44 | 18367 | 2.85 | 11.26/114.9 | 21.68 | 18.5 | 84.3/860 | |
| RS-385SH | 17110 | 6.0~24.0 | 24VDC | 11000 | 0.15 | 9034 | 0.69 | 10.7/109 | 10.12 | 3.16 | 59.8/610 |
| 2267 | 6.0~12.0 | 12VDC | 10000 | 0.17 | 8340 | 0.85 | 7.5/76.5 | 6.53 | 4.29 | 45/459 | |
Established in 2005, the enterprise is a high-tech manufacturer integrating the research, development, production and sales of various kinds of micro DC motor, geared motor, planetary geared motor, shade pole geared motor and special gearbox motor. Products are widely used in automobiles, communications equipment, smart home, medical equipment, intelligent security, household appliances, western kitchen equipment, machinery and electronics and other high-end transmission structures, exported to more than 50 countries and regions worldwide.
A: We're factory. We specialize in micro dc motor and dc gear motor more than 14 years.
A: We can draw up an Ali Assurance Order Online for our new customer, which can pay online with Mater Card, Visa, etc. Customer also can pay with PayPal or TT etc.
A: Yes, we can customize a suitable motor according to our customer's requirements.
A: Yes, we have CE, FCC, ISO, etc. If you have the other certificates requirement, we can apply it for you.
A: We have professional checking staff on every production line process. After finishing the whole motor, we have entire quality machine to test the motor. Such as Hardness Tester, 2.5D Image Tester, Salt Spray Chamber, Life Tester, Temperature Test Machine, and Noise tester etc.
Looking forward to your reply!
